Venturi Fertigation Bypass Kit with Valves and Fittings

This Venturi fertigation bypass kit combines an injector with bypass valves and fittings. Water passing through the injector creates the pressure difference that draws nutrient solution into the irrigation flow. A suitable bypass layout lets the operator adjust the injection branch and isolate it when service is needed.

Confirm the connections and kit contents

Check the mainline and bypass connection sizes against the fittings in your irrigation layout. Confirm the supplied injector, valves, adapters, suction tubing and other accessories before ordering. A connection size for the bypass does not necessarily describe every port or component in the assembly.

Check pressure difference and available flow

Venturi operation depends on the pressure difference across the injector and the water flowing through it. Confirm the inlet and outlet pressures for the planned operating condition and select the kit from the matching performance information. The solution draw rate varies with the installation; do not assume a fixed fertilizer dose from nominal connection size alone.

Install for reliable feeding and service

Provide the backflow protection required for the irrigation supply and confirm compatible tubing and fittings for the fertilizer solution. Arrange the valves so the branch can be isolated before servicing. Test the suction and feeding rate with the actual system flow, then flush the downstream lines with clean water after feeding as required by the irrigation design.

Request a matched assembly

Provide mainline size, available pressure and flow, fertilizer solution and the desired feeding duty when requesting supply. Agree the connection configuration and complete contents of one kit. Online purchasing is unavailable until that assembly and its price are confirmed.
