Click to zoom1 / 5SKU: MJ10C-15
An orange ribbed cap covers the black inlet body of this compact single-outlet misting nozzle.
$0.23
USD · per selected optionItems subtotal: $0.23 · Shipping calculated at checkout.
An orange ribbed cap covers the black inlet body of this compact single-outlet misting nozzle. Use it beside greenhouse plants where an individual mist outlet is needed.
The listed orifice is 0.5 mm, with a working range of 2-3 bar. Confirm the inlet connection and observe wetting at plant height before selecting the number and spacing of outlets.
Measure pressure with the complete irrigation zone running. Flush the supply line before connecting small outlets and use filtration suited to the nozzle opening. Check the growing medium after a watering cycle and adjust run time to avoid persistent saturation.
Inspect the opening and connections for debris or leaks. Rinse deposits away gently and avoid enlarging the nozzle with sharp tools. Recheck distribution after cleaning or changing the number of outlets.
| Parameter | Value |
|---|---|
| Diameter | 0.5mm |
| Flow Rate | 15L/h |
| Working Pressure | 2-3Bar |
| Spraying Radius | 1m |
